Qorvo Introduces Dual-Band 2.4/5 GHz BAW Diplexer for Single-Antenna Wi-Fi Systems

Why It Matters

By consolidating filtering and diplexing, the QPQ4701 cuts cost and size while improving Wi‑Fi resilience in dense, interference‑heavy environments, a critical advantage as 5G and Wi‑Fi converge.

Key Takeaways

• Dual‑band diplexer supports 2.4 GHz and 5 GHz Wi‑Fi
• Integrates filter and diplexer, eliminating external matching
• Provides high near‑band rejection against LTE/5G interference
• Low‑loss 5 GHz band‑pass design maintains wideband performance
• Targets APs, routers, gateways, CPE, IoT devices

Pulse Analysis

Qorvo’s latest offering, the QPQ4701, is a bulk‑acoustic‑wave (BAW) diplexer that merges filtering and diplexing into a single laminate module. By covering the 2.4 GHz (2402‑2482 MHz) and 5 GHz (5150‑5735 MHz) Wi‑Fi bands, the component enables true dual‑band operation over a single antenna, a design that trims PCB real‑estate and reduces BOM complexity. Engineers gain a compact, turnkey solution that sidesteps the traditional cascade of discrete filters, matching networks, and baluns, accelerating time‑to‑market for next‑gen wireless products. The BAW architecture also offers superior temperature stability compared with traditional SAW filters, reinforcing reliability in harsh industrial environments.

The 2.4 GHz path’s high near‑band rejection is engineered to suppress LTE bands B7, B38, B40 and B41, which often bleed into Wi‑Fi spectra in urban cells. This capability preserves sensitivity when Wi‑Fi coexists with high‑power cellular transmitters, a scenario becoming commonplace as 5G densifies. Meanwhile, the 5 GHz channel maintains low insertion loss across U‑NII‑1 to U‑NII‑3, supporting the wide channel bandwidths demanded by Wi‑Fi 6E and upcoming Wi‑Fi 7 deployments. Such interference mitigation is essential for carrier‑grade deployments where service‑level agreements demand consistent Wi‑Fi performance despite overlapping spectrum usage.

For manufacturers of access points, routers, residential gateways and CPE, the QPQ4701 promises a reduction in component count and board space, translating into lower production costs and smaller device footprints. As Wi‑Fi networks evolve toward higher throughput and tighter latency budgets, integrated BAW solutions like Qorvo’s are likely to become a de‑facto standard, especially in IoT edge nodes where size and power efficiency are critical. Early adopters can also leverage the component’s built‑in test points for streamlined validation during mass production, further accelerating time‑to‑revenue. Competitors will need to match the combination of broad band coverage, low loss and robust interference rejection to stay relevant in the fast‑moving RF front‑end market.
